Product Brief - Model cMT-SVR cMT-SVR

cMT-SVR 202 HMI Server

picarrow Compact Design and DIN-rail Mountable
arrow Built-in 256 MB Flash Memory
arrow SD Card Slot for Expansion of Storage
arrow One USB Host Port
arrow Fan-less Cooling System
arrow Dual Ethernet ports

Dual Port Ethernet Server supporting PLC protocols to an Ipad emulating an HMI or cMT-IV5 allowing single viewing station for multiple field units

Connect multiple HMI screens to multiple HMI Servers over your factory Ethernet network.

Each cMT-SVR HMI Server communicates with its own PLC network.

Use panel-mounted EasyView cMT-iV5's (9.7 inch display) as your user interface, or view/control your plant over Wifi from your iPad.

Applications

  • View Multiple PLC's around your network from a single HMI
  • View your plant data from multiple locations
  • Roam your factory with your iPad and still retain full plant visibility

SPECIFICATIONS

Memory

Flash:
RAM:

256 MB
256 MB

Processor:

32bit RISC Cortex-A8 600MHz

I/O Port

SD Card Slot:
USB Host:
USB Client:
Ethernet:
COM Ports:


RS-485 Dual Isolation:
HDMI:
Audio Output:
Video Input:

SD/SDHC
USB 2.0 x 1
N/A
10/100/1000 Base-T x 2
COM 1: RS232
COM 2: RS485 2W/4W
COM 3: RS485 2W
N/A
N/A
N/A
N/A

RTC:



Built-in

Power

Input Power:
Power Isolation:
Power Consumption:

24 ±10% VDC
Built-in
230mA@24VDC

Specification:

Enclosure:
Dimensions (WXHxD):
Weight:
Mounting:

Plastic
130x115x27mm
Approx 0.18kg
DIN Rail

Operation

CE:
FCC:
UL:
Voltage Resistance:
Isolation Resistance:
Vibration Endurance:
Protection Structure:
Storage Temperature:
Operating Temperature:
Operation Humidity:

CE Marked
-
cULus Listed
500 VAC (1 min)
Exceed 50MΩ at 500 Vdc
10 to 25 Hz (X,Y,Z direction 2g 30 minutes
IP20
-20~70°C (-4°~158°F)

-20°~55°C (-4°~131°F)
10-90% RH (non-condense)
Software: EasyBuilder ProV4.00.01 or later

MECHANICAL DIMENSIONS

CERTIFICATION
(Click on Certificate to View)

CE

UL

RoHS
